Description

CNC controlled point to point boring machine with
through feed panel boring from the bottom and
automatic panel return to the operator.

Workpiece driven and held by high precision toothed
belts.

Double zero reference: on leading edge by mechanical
stop, and trailing edge by laser reader.

Panel drilling from the bottom for a more accurate
drilling depth and better dust extraction.

Side aligner fence with constant pre-load for a
perfect workpiece positioning towards the side
fence

Zero setting

Three CNC controlled axes:

No limits in panel length

No tool changing

Ideal for batch 1 piece

TECHNICAL DATA
number of vertical independent spindles:  8
number of horizontal spindles:                  (2+2)
One horizontal boring spindle on axis Y
Saw blade unit (diameter 100 mm)
max. thickness of the panel                    50 mm
control full parametric
max. weight of the panel                          25 kgs
max. panel width                                      920 mm
max. panel size  X    no limit, Y 920 mm, Z 50 mm
min. panel size  X  270 mm, Y 150 mm, Z 12 mm
number of controlled axes                        3
panel feeding speed                              30 m/min
spindles speed rotation                    3.600 rpm
max horizontal diameter of the tools    12 mm
max drilling depth in horizontal
on X- and Y-axis                                    30 mm
max drilling depth in vertical                45 mm
max vertical diameter of the tools      35 mm
motor power                                          1,5 kW
CE-STANDARDS
