Description

This production line is designed for the production of honeycomb panels.
There is no panel sizing in the system,
the processed panels can have surface overhangs
and would be finished in additional machines.
The plant was controlled via a production line control PC22.

The system consists of following components:
Pos.  1  feeder, make Weinmann
Pos.  2  cleaning brush, make Wandres
Pos.  3  edge processing machine, make Homag
Pos.  4  expander- and drying machine, make Honicel
Pos.  5  honeycomb string formatting station, make
        Weinmann
Pos.  6  glue application, bottom, make Nordson
Pos.  7  glue application, top, make Nordson
Pos.  8  deposit station, make Weinmann
Pos.  9  press calendar, make Friz
Pos. 10  outfeed roller conveyor, make Weinmann
Pos. 11  stacker, make Weinmann


workpiece parameters

workpiece length:        900 – 2.500 mm
workpiece width:          300 – 1.300 mm

slat height:            16 –  44 mm
slat width:              25 –  80 mm
slat width:              50 – 100 mm

panel thickness finished part:  22 – 55 mm

honeycomb style:    thickness 16 – 44 mm,
                                  cell width: 10 – 15 mm

honeycomb board structure
- only longitudinal slats
- with longitudinal- and cross slats
- with cross and middle slats
