Description

- left hand machine
- sliding transport chain
- top pressure: wide v-belt
- anti-stick solvent applicator
- infeed table
- 1 trimming unit,
  pneumatic controllable,
  motor 3,3 kW, 100 cycles
- 1 double hogger unit,
  2 motors each 3,3/4,4 kW, 50/100 cycles
- hot melt gluing unit
  with 2 pre-melter,
  6-fold edge magazine up to 3 mm edges
- end-trimming unit mounted at the top pressure,
  2 motors each 400 W, 200 cycles
- milling unit,
  2 motors each 1.000 W, 200 cycles
- multiple milling unit, top
  motor 500 W, 300 cycles
  pneumatically adjustable
- multiple milling unit, bottom
  motor 500 W, 300 cycles
  pneumatically adjustable
- profile scraper
- flat scraper
- contour corner buffing unit
  4 motors each 0,25 kW, 50 cycles
- buffing unit, oscillating
  2 motors each 0,55 kW, 50 cycles
- free space

incl. workpiece return device
make Ligmatech
type ZHR 15/XX/Li
