Year of manufacture: 2014
Maximum edge band thickness: 8 mm
Belt top pressure: Yes
Units controled: Pneumatic
Machine length: 6,760 mm

For door dimensions:
- Lengths: 1,800 - 2,300 mm
- Widths: 500 - 1,300 mm
- Thicknesses: 35 / 40 / 44 mm

Panel size: 5,500 x 1,600 mm
Maximum pressing force: 160 tons

- Panel size: 3,500 x 1,400 mm
- Stroke: from bottom to top
- Maximum total lifting force: 110 tons

CSMA pull-out device
- Drive power: 4 x 4 kW
- Feed speed: 85 m/min

VZM centering device
- Drive power: 2 x 7.5 kW
- Feed speed: 84 m/min

- joint milling
- Gluing section with glue premelter
- Pressure zone
- Snipping unit
- Flush trimming
- Contour trimming unit FK 13 with automatic tool changer 8-fold
- Groove trimming unit
- Profile scraper
- Surface scraper
- Buffing unit
- Homatic NC 21 control unit

Travels
- X-axis: 2450 mm
- Y-axis: 1400 mm
- Z-axis: 800 mm

The JJZ-CP press is suitable for the production of plywood, doors, and MDF panel joints. The glued elements are fed and removed automatically via driven roller conveyors.

- Jointing milling unit with 2 motors, each 4.5 kW
- Infrared heater, approx. 300 mm long, 2 x 1.5 kW
- Gluing unit
- Vertical roll holder for 32 rolls
- End trimming unit on top pressure beam with 2 motors, each 200 W
- Milling unit with 2 motors, each 1000 W
- Multi-functional processing unit 2 motors 660 W
- Spray nozzles top and bottom
- Multi-profile scraper unit
- Flat scraper unit
- Copy buffing unit 4 motors 250 W
- Smoothing unit

Processing speeds per axis:
- max. 90 m/min on the X-axis
- max. 30 m/min on the Y-axis
- max. 15 m/min on the Z-axis

The line consists of:
• SORBINI Smartcoater SP1 coating rollers, built in 2009, approximately 3,000 operating hours
• SUPERFICI model 2UVPLUS65 UV lamps, built in 1998, mounted on a VENJAKOB conveyor belt, built in 1998, average operating hours: 8,500
Max. element width: 1,300 mm

- Release agent specification top/bottom
- Joining unit and blow nozzle
- Cutting unit
- Copy trimming unit SKF-L
- Profile scraper unit
- Spray cleaning agent
- Self-scanning scraper unit
- Buffing unit

- 4 rollers
- Working width: 1400(1350) mm

- Cutting length: 4200 mm
- Cutting width: 4200 mm
- APA - quick clamping system Cutting height: max. 72 mm
- Main saw motor (15 HP): 11 kW
- Scoring saw motor (3.0 HP): 2.2 kW

- Joining milling aggregate
- Gluing aggregate A15
- Cutting unit chamfer/straight
- Pre-milling unit
- Milling unit
- Universal milling unit
- Form milling unit
- Profile scraper blade
- Free space glue joint scraper blade
- Buffing unit

- Cutting speed of the sanding belt infinitely variable
- Drive of sanding unit and conveyor belt: 15 kW, frequency-controlled
- Feed speed: max. 14 m/min
- Working width: 1350 mm

Workpiece dimensions
- workpiece thickness: 12 - 40 mm
- workpiece size (L/W): min 250 x 240 mm, max. 2500 x 1200 mm
- workpiece weight: max. 50 kg

- number of chambers 3
- capacity of one chamber 90 m3
- chamber size 9.6x7.3x4.1 m
- final moisture content 10 +/- 2%

The system consists of:
- Feeder
- Transport table with a cleaner
- Spray coating machine
- Drying tunnel with IR lamps, 2 pieces
- UV tunnel
- Roller conveyor
- Turntable
- Transport table
- Transport table with a cleaner
- Spray painting machine
- Drying tunnel with IR lamps, 2 pieces
- UV tunnel
- roller conveyor

The system consists of:
- Feeder
- Transport table with a cleaner
- Spray coating machine
- Drying tunnel with IR lamps, 2 pieces
- UV tunnel
- Roller conveyor
- Turntable
- Transport table
- Transport table with a cleaner
- Spray painting machine
- Drying tunnel with IR lamps, 2 pieces
- UV tunnel
- roller conveyor

- Machining range X= 3700 Y=2100 Z= 200
- 9 kW IOX spindle
- 12-fold linear traveling tool changer
- 9 vertical drilling spindles, SCM gearbox

Workpiece dimensions
- Length: 220 cm
- Width: 150 cm
- Height: 35 cm

Sanding unit equiment:
Q / Q / L / L / L / L / Brush / Brush

- Processing range X: 4200 mm
- with standard units Y: 1200 mm
- Tool holder: HSK F63
- Design: disk changer
- Magazine places: 18

consisting of:
4 x Screw compressor
2 x Refrigeration dryer
1 x Pressure tank

Power of the 5 shafts:
- bottom: 4 Kw
- right / left: 7.5 Kw
- top: 7.5 Kw
- bottom: 4 kW

- With workpiece return
- Maximum edge thickness: 20 mm
- Panel thickness: 8-60 mm
- Maximum feed rate: 20 m/min
- With grooving unit

- working width: max. 200 mm
- working height: max. 40 mm
- workpiece length: min. 1000 mm
- feed speed: 20 m/min
