- in X-direction without gluing 6000 mm
- in X-direction motor gluing 5000 mm
- in Y-direction 1200 mm
- in Y-direction with main spindle + WZ-Ø 20 mm 1300 mm
- Tool holder: HSK F63

- Working area: X: 9000 mm / Y: 2700 mm
- Portal 1: 5-Achs-Milling spindle 20/26 kW
- Chain tool magazine with 32 positions
- Portal 2: 2x13 drilling spindles

- Working area: 5300 x 1400 mm
- Main spindle replaced 3 years ago
- 18-station tool changer

- Table size: 3100 x 2100 mm
- 4-axis main spindle
- 16-position linear tool changer
- 2 vacuum pumps
- 12 vertical drilling spindles
- 1 groove saw

Number of independent vertical spindles: 12
Number of independent horizontal spindles on the X-axis: (2+2)
Number of horizontal drilling spindles on the Y-axis: (2+2)
1 saw (Ø 100 mm)
5 kW electric spindle with ISO 30 taper (12,000-24,000 rpm)

New machine (was only stay in a school for demonstration purposes)
Number of Axes: 4
X-axis Travel: 4000 mm
Y-axis Travel: 1670 mm
Z-axis Travel: 500 mm
Spindle Power: 12 kW, 24000 RPM

Working area
X= 5540 mm
Y= 1570 mm
Z= 350 mm
5-axis main spindle
12 vertical drilling spindles
6 horizontal drilling spindles

Working area
X= 3100 mm
Y= 1550 mm
Workpiece thickness: max. 100 mm

Main spindle 9 kW HSK F63

Working length: 3500 mm
Working width: 1300 mm

tool change spindle 9 kW - HSK F63

Workpiece length max. 3000 mm
Workpiece width: max. 1300 mm
Workpiece thickness: max. 60 mm

Main spindle 7.5 kW HSK F63

Working area
X = 3300 mm
Y = 1280 mm
Z = 250 mm

Milling spindle 12 kW HSK F63

Machining range:
X = 6000 mm
Y = 1800 mm
Z = 380 mm

5-axis fork head (replaced in 2019)

Price: 30,000.00 EUR

Working area:
X=4600 mm
Y= 1935 mm
Z=275 mm

Latest version of 5-axis simultaneous machining software through maintenance contract

- X-axis speed: 80 m/min
- 18-position tool changer
- Drilling head with 30 spindles
- Working area: 6,000 x 1,550 mm

- Workpiece length: 800 - 3000 mm
- Workpiece width: 350 - 1400 mm
- Workpiece thickness: max. 70 mm with edge / max. 80 mm for milling
- Main spindle 12 kW
- 18-position disk changer

- Machining range X= 3700 Y=2100 Z= 200
- 9 kW IOX spindle
- 12-fold linear traveling tool changer
- 9 vertical drilling spindles, SCM gearbox

- Processing range X: 4200 mm
- with standard units Y: 1200 mm
- Tool holder: HSK F63
- Design: disk changer
- Magazine places: 18

consisting of:
- Portal loading system PBA-52M
- BMA-DLS-CNC drilling and assembly system
- BAD-DTW-CNC drilling and assembly system
- Feeding and buffer section
- Automatic glue application LA - CNC
- Feeding and turning device ZWA-1-CNC
- KP-6-CNC Carcass press

- Working range X: 6175 mm
- Working range Y: 1900 mm
- Working range Z: 300 mm
- Tool changing stations: 30

- Machining range with standard units: X 3000 mm, Y 1000 mm

- Processing area 4300 x 1250 mm
- 8 pcs. Workpiece support
- main spindle 7.5 Kw / 11kw
- horizontal drilling unit
- vertical drilling unit
- grooving saw
- 18-fold tool changer

- Number of vertical spindles: 9
- One grooving unit: D=100mm
- Milling spindle: 3 kW, ISO 30
- Max. Workpiece size: X=endless, Y=1100mm, Z=50mm
- Min. workpiece size: X=270mm, Y=150 mm, Z=12mm
- Workpiece transport speed: 25m/min.
- Spindle rotation speed: 3600 rpm.

- Year of manufacture 2020
- Milling spindle 2x3.5 kW
- upper and lower drilling heads
- Grooving saw
- Barcode reader

Workpiece dimensions
Length: 250 - 2500 mm
Width: 130 - 700 mm
Thickness: 16 - 19 mm
