- Veneer strip lengths (grain direction): 350 - 2150 mm
- Veneer strip widths ( cross grain direction): 50 - 600 mm
- Veneer face width (cross grain direction): min. 260 mm
- Veneer strip thickness: 0,3 - 1,5 mm

- Max. cutting length: 2600 mm
- Cutting widths: 45 - 350 mm
- Pressure beam opening: 100 mm
- Pressure beam width: 350 mm
- Parallel fence with digital read-out: 25 - 1000 mm
- Cutting angle approx.: 45°

- Veneer strip lengths (grain direction): 350 - 1500 mm
- Veneer strip widths (cross grain direction): 50 - 500 mm
- Veneer strip thickness: 0,3 - 1,5 mm

- Veneer strip lengths (grain direction): 350 - 1500 mm
- Veneer strip widths (cross grain direction): 50 - 500 mm
- Veneer face width (cross grain direction): min. 260 mm
- Veneer strip thickness: 0,3 - 1,5 mm

Lacquering of narrow edge surfaces
Put into operation: 2021
Purpose: to spray edges of furniture panels located in stacks.

Consisting of:
- Infeed unit
- Stacking Unit

- Jointing cutter
- Radiant heater
- EVA gluing unit
- Roll magazine for edge material
- Cutting unit
- Flush milling top/bottom
- MFA with 2 motors for radius r2, servo-controlled
- Profile scraper unit
- Surface scraper unit
- Buffing unit
- Feed speed 20 m/min

- working withd 1.350 mm
- Belt feed speed 2 to 16 m/min
- PRO SAND electronic control

For door dimensions:
- Lengths: 1,800 - 2,300 mm
- Widths: 500 - 1,300 mm
- Thicknesses: 35 / 40 / 44 mm

Panel size: 5,500 x 1,600 mm
Maximum pressing force: 160 tons

CSMA pull-out device
- Drive power: 4 x 4 kW
- Feed speed: 85 m/min

VZM centering device
- Drive power: 2 x 7.5 kW
- Feed speed: 84 m/min

The JJZ-CP press is suitable for the production of plywood, doors, and MDF panel joints. The glued elements are fed and removed automatically via driven roller conveyors.

- Jointing milling unit with 2 motors, each 4.5 kW
- Infrared heater, approx. 300 mm long, 2 x 1.5 kW
- Gluing unit
- Vertical roll holder for 32 rolls
- End trimming unit on top pressure beam with 2 motors, each 200 W
- Milling unit with 2 motors, each 1000 W
- Multi-functional processing unit 2 motors 660 W
- Spray nozzles top and bottom
- Multi-profile scraper unit
- Flat scraper unit
- Copy buffing unit 4 motors 250 W
- Smoothing unit

The line consists of:
• SORBINI Smartcoater SP1 coating rollers, built in 2009, approximately 3,000 operating hours
• SUPERFICI model 2UVPLUS65 UV lamps, built in 1998, mounted on a VENJAKOB conveyor belt, built in 1998, average operating hours: 8,500
Max. element width: 1,300 mm

- Release agent specification top/bottom
- Joining unit and blow nozzle
- Cutting unit
- Copy trimming unit SKF-L
- Profile scraper unit
- Spray cleaning agent
- Self-scanning scraper unit
- Buffing unit

- 4 rollers
- Working width: 1400(1350) mm

- Cutting length: 4200 mm
- Cutting width: 4200 mm
- APA - quick clamping system Cutting height: max. 72 mm
- Main saw motor (15 HP): 11 kW
- Scoring saw motor (3.0 HP): 2.2 kW

- Joining milling aggregate
- Gluing aggregate A15
- Cutting unit chamfer/straight
- Pre-milling unit
- Milling unit
- Universal milling unit
- Form milling unit
- Profile scraper blade
- Free space glue joint scraper blade
- Buffing unit

- Cutting speed of the sanding belt infinitely variable
- Drive of sanding unit and conveyor belt: 15 kW, frequency-controlled
- Feed speed: max. 14 m/min
- Working width: 1350 mm

- number of chambers 3
- capacity of one chamber 90 m3
- chamber size 9.6x7.3x4.1 m
- final moisture content 10 +/- 2%

The system consists of:
- Feeder
- Transport table with a cleaner
- Spray coating machine
- Drying tunnel with IR lamps, 2 pieces
- UV tunnel
- Roller conveyor
- Turntable
- Transport table
- Transport table with a cleaner
- Spray painting machine
- Drying tunnel with IR lamps, 2 pieces
- UV tunnel
- roller conveyor

The system consists of:
- Feeder
- Transport table with a cleaner
- Spray coating machine
- Drying tunnel with IR lamps, 2 pieces
- UV tunnel
- Roller conveyor
- Turntable
- Transport table
- Transport table with a cleaner
- Spray painting machine
- Drying tunnel with IR lamps, 2 pieces
- UV tunnel
- roller conveyor

Workpiece dimensions
- Length: 220 cm
- Width: 150 cm
- Height: 35 cm

- With workpiece return
- Maximum edge thickness: 20 mm
- Panel thickness: 8-60 mm
- Maximum feed rate: 20 m/min
- With grooving unit

Sanding belt width: 300 mm
Sanding belt length: 1800 mm
Max. working height: 200 mm Working height: 200 mm
Feed speed: 6 / 11 / 16 m/min

Working width 1100 mm
Working height max. 200 mm
Sanding roller
Sanding pads for lacquer sanding
Belt cleaning

Combined sawing unit with
Cross cutting aggregate with cutting length 1.600 mm and with
Depth cutting aggregate with cutting length 5.600 mm

With vacuum feeding device and outfeed roller conveyor

carcass dimensions:
Length: min. 300 mm / max. 2300 mm
Height: min. 300 mm / max. 1220 mm
Depth: max. 600/800/1000 mm (depending on press type)
