- 1 Saw unit with scoring saw
- 1 horizontal drilling unit
- Glue application- and dowel inserting station
- 1 Vibrational conveyor

Price: 12.000,00 €
Reduced price: 8.900,00 €

- Working area 1300 x 50 x 50mm
- drilling head 3.500 rpm
- 3 horizontal indipendent spindles
- 3 vertical indipendent spindles
- 1 glue and dowels inserting unit

- 32 pitch
- Setting coul. 4,0
- 380 volt

- max. immersion depth 160 mm
- Motor power 0.65 kW

Drilling depth 23 mm
Motor power 0,52 kW

Price: 790.00 EUR + VAT.

Drill chuck: B16
Drilling depth / spindle stroke: 80 mm

Speeds: 400/630/1000/1600/2500/4000 rpm
Motor: 0.55kW, 380V, 50Hz, 1.65A

Drill chuck holder: B12
Drill chuck stroke: 40mm
Distance from column to drilling area: 180mm
Thickness of the column: 50mm
Worktop: 180x260mm

Price: 820,00 €

21 spindles, 32mm spacing
drilling gear swivable (drilling from below and behind)
2 pneumatic clamps (pressing from top)
380V/50Hz/3P

21 spindles, 32mm spacing
drilling gear swivable (drilling from below and behind)
2 pneumatic clamps (pressing from top)
380V/50Hz/3P

List price: 1,450.00 € (+ VAT.)
Special price: 1,150.00 € (+ VAT.)

1 drilling gear with 10 spindles
Price: 750.00 EUR + VAT

21 spindles, swiveling boring head

23 spindle
working width approx. 800 mm

List price: 3,000.00 € (+VAT.)
Special price: 2,400.00 € (+ VAT.)

Drehzahl 3000 - 4800 UpM

For workpieces
Length 300-2500mm
Width 200-800mm
Thickness 15-26mm

For workpieces
Length 350-800mm
Width 400-1000mm
Thickness 19-25mm

max. drilling depth: 40 mm
max. drilling Ø: 25 mm

The machine is prepared to be equipped with bottom and top vertical boring groups.
- working table: 2800 mm
- 2 horizontal boring heads with 21 spindles each prepared for quick chucks
- The right one is movable with the possibility to pass over the vertical boring groups

- 2800 mm working table
- 5 glue injectors and dowels-inserters for each side
- Tank for automatic nozzle cleaning
- 2 CN programable stops
- This machine is arranged in advance to receive a max. of 4 bottom boring groups and 6 glue injectors dowels-inserts for each side

- 2800 mm working table
- PLC and touch screen
- 2 horizontal boring heads with 21 spindles each prepared for quick chucks
- 2 CN programable stops

- one boring head 35 spindles / 32 mm grid
- pneumatic cylinder for horizontal/vertical positioning of the boring group

- Digital display
- Swiveling drill bar
- Drilling speed and depth adjustable
- Reliable dimensional reference between horizontal and vertical holes

- 1 drilling unit 21 spindles / 32 mm spacing
- Drilling unit swivable 45 degree and any intermediate angles
- Front/top caliper to obtain the same drilling measure between horizontal and vertical position
