with milling and gluing unit for butt joint gluing

- Veneer bundle length (grain direction): 400 - 4000 mm
- Veneer bundle widths (cross grain direction): 45 - 515 mm
- Veneer bundle thickness: approx. 10 - 40
- Throughput speed: approx. 27 m/min.

- Veneer bundle lenght (grain direction): 400 - 4000
- Veneer bundle widths (cross grain direction): 45 - 515 mm
- Veneer bundle thickness: approx. 10 - 40 mm

- Cutting width: 800 mm
- Insertion height: 70 mm
- Weight: approx. 1100 kg

- max. cutting opening: 1060 x 75 mm
- external dimensions of machine: 1700 x 700, height 1700

- Veneer face lengths (grain direction): 400 - 2800 mm
- Veneer face widths (cross grain direction): 400 - 4200 mm
- Veneer thickness (trimming and reinforceing mode): 0,3 - 1,5 mm
- Veneer thickness (reinforcing mode only): 0,3 - 2,0 mm
- Trim-off widths (each side): 10 - 350 mm

- Veneer face lengths (grain direction): 420 - 2800 mm
- Veneer face widths (cross grain direction): 400 - 4200 mm
- Veneer thickness (trimming and reinforcing mode): 0,3 - 1,5 mm
- Veneer thickness (reinforcing mode only): 0,3 - 2,0 mm
- Trim-off widths (each sids): 10 - 350 mm

- Veneer strip lengths (grain direction): 350 - 2150 mm
- Veneer strip widths ( cross grain direction): 50 - 600 mm
- Veneer face width (cross grain direction): min. 260 mm
- Veneer strip thickness: 0,3 - 1,5 mm

- Cutting length: 2810 mm
- Insertion height: 80 mm
- Cutting range: 20 - 470 mm
- Drawing motion of knives approx.: 20°

- Max. cutting length: 2600 mm
- Cutting widths: 45 - 350 mm
- Pressure beam opening: 100 mm
- Pressure beam width: 350 mm
- Parallel fence with digital read-out: 25 - 1000 mm
- Cutting angle approx.: 45°

- Veneer strip lengths (grain direction): 350 - 1500 mm
- Veneer strip widths (cross grain direction): 50 - 500 mm
- Veneer strip thickness: 0,3 - 1,5 mm

- Veneer strip lengths (grain direction): 350 - 1500 mm
- Veneer strip widths (cross grain direction): 50 - 500 mm
- Veneer face width (cross grain direction): min. 260 mm
- Veneer strip thickness: 0,3 - 1,5 mm

arm length: 1.200 mm
veneer thickness: 0,4 - 2 mm
feed speed: 5 - 40 m/min.

Arm length: 1.000 mm
Veneer thickness: 0,4 - 1,5 mm
Feed speed: 8 - 18 m/min.

- with automatic feed


new machine

new machine

Veneer thickness 0,4 - 4 mm
Min. veneer length 350 mm
Min. veneer width 45 mm

Cutting length: 3.600 mm
Daylight opening of the clamping beam: 100 mm
Max. rear feed width 800 mm
Min. rear feed width 25 mm
