heating plates: 3500x1300mm
electrically heated
pressing force: 120t

Fast - Silent - Clean - Lean - Universal - Service by Wehrmann

Arbeitsbreite: 1300 mm
Anlagengeschwindigkeit: 15 - 45 m/min
Plattendurchlauf: zentrisch

Example:
- useful working width: about 900 mm
- lamination: aluminum foil bottom and top


Individual compilation, "tailor made" for your Company and your products on request!

- Electric-heating plates 3.000x1.300mm
- Total pressure 120 to.
- Electronic control unit
- Setting and monitoring of press time and pressure

- new machine -
Plate dimensions 3000 x 1300 mm
Stroke 400 mm
no. 6 press cylinders
Pressing force: 90 tons

Laminating rollers Ø 150 mm
Working width 1.300 mm
Max. workpiece thickness 80 mm
Speed adjustable 5/25 m/min
Working height (adjustable +/- 20mm) 905 mm

Press are: 3000x1300 mm
Amount cylinders: 6
Daylight: 400 mm
Total pressure: 90t

Press are: 2500x1300 mm
Amount cylinders: 6
Daylight: 400 mm
Total pressure: 90t

- Hydraulic motor power: 5.5 kW
- Container dimensions: approx. 1044 x 1044 x 1010 mm
- Briquette Ø 50mm
