multi-blade saw

multi-blade saw
Brand: Winter
Type: MBS - 930
Year of manufacture: 2020


Technical data
- Working width: 200 - 930 mm
- Cutting height: 5 - 30 mm
- Min. workpiece length: 550 mm
- Spindle diameter: 74 mm
- Saw shaft speed: 2600 rpm
- Max. 30 saw blades on saw shaft
- Motor power 22 kW
- Voltage 400 V / 50 Hz
- Motor feed 1.5 kW
- Total connection 23.5 kW
- Feed speed: 0 - 12 m/min
- Feed rollers 6 pairs (12 pieces)
- Extraction connection: 150 mm
- Dimensions: L= 2200, W=1500; H=1250 mm



Note:
The technical data and descriptions are copies of the order confirmation at the time. The information is for informational purposes only and is not binding.
