Used Single-Sided Edge Banding Machine
Manufacturer: IMA
Model: Novimat Concept / I / G80 / 440 / R3 +

Single-sided Automatic IMA Edge Banding and Post-Processing Machine
Type: Novimat / Concept / I / G80 / 440 / R3+

Workpiece Specifications:

Minimum workpiece length: 150 mm
Minimum workpiece width: 65 mm
Minimum workpiece thickness: 8 mm
Maximum workpiece thickness: 60 mm
Smallest workpiece: 150 mm x 150 mm or 65 mm x 300 mm
Edge Material:

Minimum height: 14 mm
Maximum height: 65 mm
Roll Material:

Minimum thickness: 0.3 mm

Maximum thickness: 3.0 mm*

Veneer edges restricted to a maximum of 1.0 mm
Infeed table 63.152, approx. 500 x 500 mm

Brush support for infeed table 63.152

Release agent application, top and bottom

Joint Milling Unit 08.379:

With 2 motors, each 4.0 kW, 8800 RPM, 150 Hz, adjustable
Horizontal adjustment with NC control
Vertical adjustment with mechanical digital display
Air nozzle for removing loose particles from the workpiece edge

300 mm heater for preheating workpiece edges up to 60 mm

Glue Application Unit VTG:
For gluing straight edges up to 3 mm with precise starting functionality.

Edge material: 0.3 – 3 mm
Glue application for workpiece thicknesses up to 60 mm,
featuring a pneumatic quick-lock system, Chem-Coat coating, and electronic temperature control.

Automatic Quickmelt hot glue feeder 283.205

Heating power: 5.0 kW
Automatic granulate feeding from a storage tank (approx. 30 kg capacity)
6-slot edge magazine for roll material 0.3 – 3 mm thick
and maximum workpiece thickness of 60 mm.

End Trimming Unit 08.42 / 30 / B
Pneumatic swiveling 0°+25° for straight and bevel trimming cuts.
Automatic adaptation to feed speeds of 20+30 m/min.

With 2 motors, 660 kW
Milling Unit 08.0555

With 2 motors
Multi-Profile Milling Unit 08.0587

With 2 motors
Contour Milling Unit 08.355, KFA x30

Multi-Profile Scraper Unit 08.516

Spray nozzles, top and bottom, for applying cleaning agents

Scraper Unit 08.521

Buffing Unit 08.617-4

Board Return System Feedback 3.2 (Custom Design)

With double-angle transfer for single-sided edge banding machine Novimat Type 440
Components:

1 piece powered roller conveyor, infeed
1 piece cross conveyor
1 piece powered roller conveyor, outfeed
1 piece transport belt
1 piece angle transfer
1 piece air-cushion table
1 piece air-cushion table
1 piece safety fence


Note:
The technical data and descriptions are taken from the original order confirmation.
These details are for informational purposes only and are non-binding.
