Veneer Cross Cutter

Veneer Cross Cutter
Brand: Monguzzi, Carugate
Type: ASHO-800
Year of manufacture: 2006


Strong built, hydraulic driven machine for fast and economic cutting of veneer bundles to length.

Technical data:
Cutting width: 800 mm
Insertion height: 70 mm
Weight: approx. 1100 kg

Features
- Upper part is open ti the front enabling to load the veneers from the right, left or front side
- Aligning fence on right side in feed direction
- Hydraulic controlled blade and pressure beam
- Cut against plastic cutting strip
- Auto-controlled photocells and protective grating
- Two-hand pushbutton control



Note:
The technical data and descriptions are copies of the order confirmation at the time. Data is for information purposes only and is not binding.
