single-sided edge banding machine

used one-sided edge banding machine
Make: Homag
type: Profi KAL 330/ 9/A6/L

Year of construction: 2011

- with portal return Barbaric -

Single-sided edge banding machine for processing straight workpiece edges and for gluing and reworking various edge materials in longitudinal and transverse throughfeed.

- with Lasertec and PU gluing
- with portal return Barbaric

Basic machine:
- Machine stand continuous, for mounting the processing units.
- Fixed stop side left
- Painted gray RDS 240 80 05
- Adjustable infeed fence
- Pneumatically controlled infeed stop

- Top pressure:
- Composite V-belt driven
- Electronic height adjustment
- Digital position indicator

- Workpiece transport device:
Transport chain with rubber pad, 80 mm wide
Hardened precision running and guide surface
- Magnetically braked transport chain
- Workpiece support with roller rail, extendable by approx. 800 mm
- Noise protection for joining and aggregate part with individual extraction

Feed rate:
- 18 m/min
(feed rate optional)
- 18-25 / 18-32 m/min

Working height:
- 950 mm

Pneumatic connection:
- 6 bar
- Ground conditions must comply with the foundation plan.

Workpiece and edge parameters:
Workpiece width without edge min:

For workpiece thickness 12-22 mm:
- 60 mm

For workpiece thickness 23-60 mm:
- 100 mm

( depending on the workpiece length)

Workpiece stock:
- 30 mm

Workpiece thickness:
- 12-60 mm
(Workpiece thickness optional: 80/100 mm

Edge material roll:
0.3-3 mm²

Edge cross-section max:
- For PVC: 135 mm²
- For veneer: 100 mm²

Roll diameter max.
- 830 mm²

Edge material strips:
Edge cross-section max. for strips:
- 900m²

- The machine arm is responsible for the use of suitable materials (panels, adhesives, edgebands, cleaning agents, paints, etc.).

Assembly of the unit:
- Free space for the installation of a joint trimming unit
(for joint trimming of the workpieces before gluing)

Gluing unit A20 basic:
Workpiece preheating:
- For heating the edge of the workpiece before glue application
- To improve the gluing quality

Quickmelt application unit:
- Electronic temperature control with LED display.
- Glue temperature reduction automatically when work is interrupted (time freely selectable)
- Melting capacity up to max. 12 kg / h
- Glue roller drive during feed stop
- Glue container lift at feed stop
- Glue container clamping workpiece-operated

Magazine 1 roll:
- For solid edges, strips and rolls
- Automatic strip separation via vacuum suction cup
- 1 edge feeder
- Roll separating device
- Edge monitoring with feed stop
- Edge sequence control for preselecting the edge channels in any sequence. If an edge channel is empty, the next selected channel is activated (with multiple magazine)

Pressure zone C
- 1 driven pre-press roller Ø 150 mm
- 6 post-pressing rollers Ø 70 mm
- Pneumatic pressure adjustment
- Central adjustment to different edge thicknesses

Free space for processing units
- For further processing units, see options list

Electrical equipment:
- Operating voltage 400 Volt, 50/60Hz
- Mounted switch cabinet
- Installed according to European standard EN 60204
- Electronic frequency converter with motor braking function
- Country-specific operating voltage adjustment via transformer (optional)
- RCD protection circuit only permissible in conjunction with an all-current sensitive/selective RCD. If the performance of this device is not sufficient, we recommend using a residual current monitoring device on site
- Prescribed ambient temperature:
+ 10 to + 40 ° C

Documentation:
- Documentation on CD-ROM
- Operating and maintenance instructions also in printed form

Infinitely variable feed rate 18-25 m/min left
- Instead of feed rate 18 m/min
- Feed rate frequency-controlled
- Speed setting on the input unit

- Manual changeover from laserTec to PU/EVA
- Designed for straight workpiece edges, no softforming

Consisting of:
- For melting the laser activation layer on the edgeband material.
- Oscillating laser beam
- Automatic adjustment to the workpiece thickness
- Laser beam wavelength 980 nm

Laser safety device:
- Laser certificate protection class 1 (the machine can be operated without additional protective measures).
- The laser corresponds to laser protection class 4 and is converted to laser class 1 by the protective device.
- The operator may not carry out any service work on the laser.

Note:
The specifications and descriptions are a copy of the order confirmation at that time. Data are for information and are not binding.
