Travels
- X-axis: 2450 mm
- Y-axis: 1400 mm
- Z-axis: 800 mm

Axes: 4 (X/Y/Z - C)
Operating hours: approx. 29,307 hours
Number of parts: approx. 300,411 pieces

The JJZ-CP press is suitable for the production of plywood, doors, and MDF panel joints. The glued elements are fed and removed automatically via driven roller conveyors.

- Jointing milling unit with 2 motors, each 4.5 kW
- Infrared heater, approx. 300 mm long, 2 x 1.5 kW
- Gluing unit
- Vertical roll holder for 32 rolls
- End trimming unit on top pressure beam with 2 motors, each 200 W
- Milling unit with 2 motors, each 1000 W
- Multi-functional processing unit 2 motors 660 W
- Spray nozzles top and bottom
- Multi-profile scraper unit
- Flat scraper unit
- Copy buffing unit 4 motors 250 W
- Smoothing unit

Processing speeds per axis:
- max. 90 m/min on the X-axis
- max. 30 m/min on the Y-axis
- max. 15 m/min on the Z-axis

The line consists of:
• SORBINI Smartcoater SP1 coating rollers, built in 2009, approximately 3,000 operating hours
• SUPERFICI model 2UVPLUS65 UV lamps, built in 1998, mounted on a VENJAKOB conveyor belt, built in 1998, average operating hours: 8,500
Max. element width: 1,300 mm

- Touchscreen control
- Joint milling
- Gluing unit with two Teflon-coated glue pans
- Release agent dispenser
- Snipping unit
- Pre-milling unit
- Rounding unit
- Profile scraper blades
- Surface scraper blades
- Buffing unit

- 4-axis milling spindle 7,5 KW 8000-24000 rpm, with automatic 18-fold rotation changer.
- 3-axis milling spindle 4 Kw. 7500-12000 rpm, with manual tool changer
- HSK 63F
- volautomatic set-up table
- safety tread mats
- IMAWOP 6.0
- Machining range X = 3000 mm
- machining range Y = 1200 mm

- Release agent specification top/bottom
- Joining unit and blow nozzle
- Cutting unit
- Copy trimming unit SKF-L
- Profile scraper unit
- Spray cleaning agent
- Self-scanning scraper unit
- Buffing unit

- 2 motors 11 kw (15 hp) each
- productivity max 850 kg/hour
- upper opening 1220×1020 mm
- lower opening 562×462 mm
- cutting knives diameter 235 mm

- 4 rollers
- Working width: 1400(1350) mm

- Cutting length: 4200 mm
- Cutting width: 4200 mm
- APA - quick clamping system Cutting height: max. 72 mm
- Main saw motor (15 HP): 11 kW
- Scoring saw motor (3.0 HP): 2.2 kW

- Joint trimming unit
- Gluing unit
- Snipping unit
- Pre-milling unit
- Shaping trimming unit
- Profile scraper blades
- Surface scraper blades
- Buffing unit
- Grooving unit

- Cutting speed of the sanding belt infinitely variable
- Drive of sanding unit and conveyor belt: 15 kW, frequency-controlled
- Feed speed: max. 14 m/min
- Working width: 1350 mm

Workpiece dimensions
- workpiece thickness: 12 - 40 mm
- workpiece size (L/W): min 250 x 240 mm, max. 2500 x 1200 mm
- workpiece weight: max. 50 kg

packaging machine:
- Welding length: 2500 mm
- Number of upper film rolls: 3
- Upper film width: max. 2450 mm
- Number of lower film rolls: 3
- Bottom film width: max. 1450 mm
- Belt width: 1300 mm

Shrink tunnel:
- Length (heated zone): 2700 mm
- Total length: 3700 mm
- Transport width: 1500 mm

- Working area:
X = 3060 mm,
Y = 1260 mm,
Z = 150 mm
- 7 kW (9.5 HP) electrospindle with ISO 30 adapter
- BH 21L drill head

- number of chambers 3
- capacity of one chamber 90 m3
- chamber size 9.6x7.3x4.1 m
- final moisture content 10 +/- 2%

system consists of:
- Weinig UC Matric
- Weinig Unimat 23 EL
- Schleifmaschine Roto Finish
- Weinig Unirex
- Weinig Unitec
- Weinig Univar
- Wender
- Beipass für Bestückung Biesse
- Auslaufförderer
- Biesse WinLine One
- Biesse Parternosterpuffer
- Biesse Portal 1
- Biesse Portal 2
- Biesse Rundbogentisch
- Biesse Flexstoor 1 and 2

system consists of:
- Weinig UC Matric
- Weinig Unimat 23 EL
- Schleifmaschine Roto Finish
- Weinig Unirex
- Weinig Unitec
- Weinig Univar
- Wender
- Beipass für Bestückung Biesse
- Auslaufförderer
- Biesse WinLine One
- Biesse Parternosterpuffer
- Biesse Portal 1
- Biesse Portal 2
- Biesse Rundbogentisch
- Biesse Flexstoor 1 and 2

The system consists of:
- Feeder
- Transport table with a cleaner
- Spray coating machine
- Drying tunnel with IR lamps, 2 pieces
- UV tunnel
- Roller conveyor
- Turntable
- Transport table
- Transport table with a cleaner
- Spray painting machine
- Drying tunnel with IR lamps, 2 pieces
- UV tunnel
- roller conveyor

The system consists of:
- Feeder
- Transport table with a cleaner
- Spray coating machine
- Drying tunnel with IR lamps, 2 pieces
- UV tunnel
- Roller conveyor
- Turntable
- Transport table
- Transport table with a cleaner
- Spray painting machine
- Drying tunnel with IR lamps, 2 pieces
- UV tunnel
- roller conveyor

- Press dimensions: 2500 x 1500 x 600 mm

- Machining range X= 3700 Y=2100 Z= 200
- 9 kW IOX spindle
- 12-fold linear traveling tool changer
- 9 vertical drilling spindles, SCM gearbox

Workpiece dimensions
- Length: 220 cm
- Width: 150 cm
- Height: 35 cm

Sanding unit equiment:
Q / Q / L / L / L / L / Brush / Brush

- Processing range X: 4200 mm
- with standard units Y: 1200 mm
- Tool holder: HSK F63
- Design: disk changer
- Magazine places: 18
