Drawer parts machining in compact design

IDEAL MACHINE FOR NARROW PARTS PROCESSING IN THE FURNITURE

- 2800 mm working table
- PLC and touch screen
- 2 horizontal boring heads with 21 spindles each prepared for quick chucks
- 2 CN programable stops

With the Windsand 4 you achieve the highest quality for your windows, doors or glued frames.

for moulding
or saw blade package
Position of tool spindle 90°

for boring, routing,
and sawing
Angle adjustment 2 x 0 – 100°
on two sides adjustable

for boring,
routing and sawing
With two tool interfaces,
angle 90°

for boring,
routing, and sawing
With one tool interface,
angle 90°

Floating Saw
CNC Aggregate for sawing
With sleigh
horizontal operations

With surface copying function
with fix spindle ER25 and fix bell

to machine material
from underneath

for corner notching
in off-set design

for boring
and routing
with two tool interfaces
angle 90°

with oscillating cutter head

for boring,
routing, and sawing
With adjustable angle 0 – 100°

for boring and routing
With four tool interfaces
2x boring / 2x routing
angle 90°

for boring, routing,
and sawing
With two tool interfaces,
angle 90°

for boring,
routing, and sawing
With one tool interface,
angle 90°

- More stability thanks to the lower brush position
- 600mm long brushes with 270mm large diameter for structuring

The best solution for grinding individual parts such as for window profiles or strips.

Antriebsmotor: 7,5 kW
Saugstutzen Ø 300mm
Volumenstrom: 5950 m³/h
Abmessungen (LxBxH) 3550 x 1580 x 2570mm

The compact sanding machine for sanding doors and windows.

Variant with motorized filter cleaning.
No compressed air connection necessary.

Drive motor: 4 kW, 400 V, 50 Hz, 3 Phases
Filter surface: 14,5 m²
Filter cleaning: pneumatical (manual release)
Air consumption: approx. 3,5 l at 8 bar
Sound pressure level: 75 dB (A)

max. cutting length: 3200 mm
max. cutting height: 1900 mm
highest horizontal cut: 1700 mm
engine power: 5 hp (3.7 kW)

Made for Batch1. Different length and width in the mix !

For contoured, concave, convex and straight workpiece edges, from 10-60 mm thickness and 1-3 mm edge thickness.

- For corner rounder and straight corners
- Standard cutters 15° R2 mm or R3 mm
- Movable reference with mechanical digital readout

with:
- Tiltable trimming unit ( with 1 high frequency motor HP 0.75 (kw0,55)
- 1 cutter Head with 2 knives 1 straight 15 degrees, the other 2 mms radius

- 1 glue spreading roller 60 mm high;
- Guillotine to cut bands up to 3 mm thickness;
- Plastic cups to raise the piece above the table
